BOSCH 0 332 019 110 Relay, main current

Normally open contact , 30 a, 12 v

Article Number: 0 332 019 110

Switch Function

Normally Open Contact

Current Strength (A)

30

Voltage (V)

12

Number of pins

4

Relay function

Normally open contact

Housing Type

Synthetic Material Housing

Protection Type (IP Code)

IP5K4

Temperature range from (°C)

-40

Temperature range to (°C)

100

Housing Colour

black/grey

Supplementary Article/Supplementary Info

with holder

Resistor (ohm)

16

0209709010 - AEBI000 402 513 3 - AUDI017 193 750 3 - AUDI025 191 950 5 - AUDI035 799 813 9 - AUDI04025133 - AUDI042 097 171 3 - AUDI043 195 125 3 - AUDI043 195 125 4 - AUDI080 394 158 7 - AUDI082 195 125 3 - AUDI086 790 638 1 - AUDI141 951 253 A - AUDI141 951 253 B - AUDI171 919 505 A - AUDI171 937 503 A - AUDI2D0919505 - AUDI311 963 141 B - AUDI4H0 951 253 A - AUDI420 971 713 A - AUDI420 971 713 AF - AUDI420 971 713 AG - AUDI420 971 713 K - AUDI420 971 713 L - AUDI420 971 713 M - AUDI420 971 713 N - AUDI431 951 253 A - AUDI431 951 253 B - AUDI443 951 253 C - AUDI443 951 253 K - AUDI6U0 906 061 A - AUDI8D0 951 253 A - AUDI8K0951253 - AUDI0867511 - DAF90464759 - GMC60193651 - IVECO21050 3747210 20 - LADAA 002 542 07 19 - MERCEDES-BENZ002 542 07 19 - MERCEDES-BENZ62 38 522 - OPEL62 38 525 - OPEL90511178 - OPEL77 00 810 395 - RENAULT000 402 513 1 - SEAT019 191 125 1 - SEAT04025131 - SEAT043 195 125 4 - SEAT080 394 158 7 - SEAT1L0941595 - SEAT141 951 253 A - SEAT141 951 253 B - SEAT171 937 503 A - SEAT4H0 951 253 A - SEAT431 951 253 A - SEAT431 951 253 H - SEAT8D0 951 253 A - SEAT8K0951253 - SEAT000 402 512 5 - SKODA000 402 512 6 - SKODA000 402 512 9 - SKODA04025125 - SKODA04025126 - SKODA04025129 - SKODA043 195 125 4 - SKODA080 394 158 7 - SKODA141 951 253 A - SKODA141 951 253 B - SKODA171 937 503 A - SKODA4H0 951 253 A - SKODA431 951 253 A - SKODA8D0 951 253 A - SKODA8K0951253 - SKODA06238522 - VAUXHALL06238525 - VAUXHALL90511178 - VAUXHALL30652083 - VOLVO000 402 513 3 - VW017 193 750 3 - VW025 191 950 5 - VW035 799 813 9 - VW04025133 - VW042 097 171 3 - VW043 195 125 3 - VW043 195 125 4 - VW080 394 158 7 - VW082 195 125 3 - VW086 790 638 1 - VW141 951 253 A - VW141 951 253 B - VW171 919 505 A - VW171 937 503 A - VW2D0919505 - VW311 963 141 B - VW4H0 951 253 A - VW420 971 713 A - VW420 971 713 AF - VW420 971 713 AG - VW420 971 713 K - VW420 971 713 L - VW420 971 713 M - VW420 971 713 N - VW431 951 253 A - VW431 951 253 B - VW443 951 253 C - VW443 951 253 K - VW6U0 906 061 A - VW8D0 951 253 A - VW8K0951253 - VW5139526 - CASE IH86400244 - CASE IH3387326M2 - MASSEY FERGUSON6005011023 - CLAAS4287339M1 - FENDTAL 20 859 5 - JOHN DEERE1367472E49477764770951304 - ROSENBAUER

Out of Stock

£2.59

Includes VAT

Delivery cost not included

Dispatch time: 1-2 business days

Alternative parts that would fit

Relay, fuel pump

BOSCH 0 986 332 302 Relay, fuel pump

Article number

0 986 332 302

£2.50

Price per item

Price details Price including delivery

Relay, main current

BOSCH 0 986 332 209 Relay, main current

Article number

0 986 332 209

£3.58

Price per item

Price details Price including delivery

Relay, main current

BOSCH 0 986 332 212 Relay, main current

Article number

0 986 332 212

£4.43

Price per item

Price details Price including delivery

Relay, main current

BOSCH 0 986 332 300 Relay, main current

Article number

0 986 332 300

£1.98

Price per item

Price details Price including delivery

Relay, main current

BOSCH 0 986 AH0 251 Relay, main current

Article number

0 986 AH0 251

£2.86

Price per item

Price details Price including delivery
